PowerVerter APS Inverter/Charger - Reliable Power

Source for Uninterruptible Emergency Backup

Applications

MODEL NUMBER: APS1012

Description

Tripp Lite's APS1012 3-function DC-to-AC inverter with auto line-to-battery transfer and integrated charging

system serves as an extended run UPS, a standalone power source or an automotive inverter. Supplies up to

1000 watts of continuous 120V AC power to 2 AC outlets from any 12V battery or automotive DC source.

PowerVerter APS Inverter chargers accommodate peak surge demands by delivering more output power than

their continuous rating. PowerVerter APS Inverters supply up to double their output to easily handle equipment

start up and motor cycling requirements. A DoubleBoost feature provides up to 200% of the continuous output for

up to 10 seconds, providing the extra power needed to cold start heavy-duty tools and equipment. An

OverPower feature delivers up to 150% of the continuous output for up to 1 hour. When AC cable is connected to

a live wall socket, commercial power passes through to connected equipment and the battery set is recharged

via 3 stage, 14/55 amp selectable charging system. In UPS mode, the APS system responds to blackouts and

brownouts with an uninterrupted transfer to battery-derived AC output. Includes a set of high current DC input

terminals for simple installation (user supplies batteries and cabling). Reliable large transformer design with

efficient PWM sine wave output and frequency control powers resistive electronic loads or large inductive

motors, compressors and other items with high current needs on startup. Supports an unlimited amount of

runtime with any number of user-supplied batteries connected. Highly adaptable to a variety of applications and

site conditions with adjustable charger settings for wet/gel battery types and selectable line to battery power

transfer voltages.

Features

Functions as an extended run UPS system, standalone power source and automotive inverter

Includes AC input cord and auto-transfer to enable battery charging and automatic UPS support for blackouts

and brownouts

1000 watts continuous output power; 2000 watts power for up to 10 seconds; 1500 watts power for up to an

hour

Battery runtime is dependent upon the size and number of user-supplied 12-volt batteries used

2 outlets; 6-ft. AC power cord; DC input terminals for 12V battery connection

Converts 12V DC to 120V AC

Frequency control for operating stability

Highlights

12V DC input; 120V AC output

2 outlets

1000 watts continuous output

2000 watts peak output for

extended period

Advanced battery charger

Fast load switching with less

transfer time

Applications

Extended Run UPS - Configure

as a UPS for long-term battery

support of telecom systems,

security alarms, computer

systems and various other

motorized and electronic loads.

Standalone Power - Alternative

power source for use in off-grid,

backwoods, alternative energy

and export applications where

commercial power is not

continuously available.

Automotive - Connect to an

automotive electrical system to

run power tools, computers,

electronic test equipment, home

entertainment and other AC

appliances in fleet service

vehicles, over-the-road trucks,

campers, RVs, minivans and

more.

Package Includes

APS1012 Inverter/Charger

Instruction manual with warranty

information

Advanced 14/55 amp selectable, 3-stage battery charger and selector switch for gel or wet cell batteries

Resettable circuit breaker protects APS against system overload

Switch allows user to select between off, auto-invert and charge-only settings

6 diagnostic LEDs indicate AC present, on battery, overload, & battery voltage level (high, medium, & low)

Configuration switches to allow the user to select the high and low voltage for the unit to automatically transfer from AC power to battery backup

Coated internal circuit boards offer continuous operation in humid environments (0-95%, non condensing)

RJ45 port allows connection of APS/PowerVerter Remote Switch (manuf# APSRM4 )
